Huizhou EVE Energy was established in 2001, and became listed on Shenzhen GEM in 2009 as the first listed enterprise with lithium battery for principle work. As a national high-tech enterprise, EVE focuses on lithium battery innovation and manufacture. After 33 years’ accumulation and 15 years’ endeavour, EVE now stands in the leading position of national lithium primary battery, and takes front position worldwide in lithium thionyl chloride battery manufacture. In recent 3 years, EVE has invested 5 billion in power storage filed, and adopted highly automatic and informationalized manufacture approach in providing first-class service to clients.
LiSOCL2
Lithium thionly chloride batteries have a lithium metal anode and thionly chloride (SOCl2) active cathode depolarizer and electrolyte solvent, using bobbin construction and is more suitable for low discharge current application.
Key Features
- High and stable operating voltage: 3.6V
- Wide Operating Temperature Range: -60℃to +85℃.
- High Energy Density: 650wh/kg and 1280wh/dm3.
- Low self-discharge rate: (less than≤1% per year at 20℃). So, it can store above 10 years at ambient temperature.
Standard Type
| Model | Size | Nominal Capacity (mAh) | Nominal Voltage (V) | Diameter (mm) | Height (mm) | Weight (g) | Max. Continuous Current (mA) | Max. Pulse Current (mA) | Data Sheet |
|---|---|---|---|---|---|---|---|---|---|
| ER14250C | 1/2AA | 1200 | 3.6 | 16.8 | 28.6 | 10 | 15 | 50 |  |
| ER14250 | 1/2AA | 1200 | 3.6 | 14.5 | 25 | 10 | 15 | 50 | |
| ER14335 | 2/3AA | 1650 | 3.6 | 14.5 | 33.5 | 12 | 35 | 75 | |
| ER14505 | AA | 2400 | 3.6 | 14.5 | 50.5 | 50 | 150 | 200 | |
| ER17505 | A | 3400 | 3.6 | 17.5 | 50.5 | 26 | 130 | 180 |  |
| ER18505 | - | 4000 | 3.6 | 18.5 | 50.5 | 28 | 130 | 180 | |
| ER26500 | C | 8500 | 3.6 | 26.2 | 50 | 52 | 75 | 200 | |
| ER34615 | D | 19Ah | 3.6 | 34 | 61.5 | 100 | 230 | 400 | |
Prismatic
| Model | Size | Nominal Capacity (mAh) | Nominal Voltage (V) | Size (mm) | Weight (g) | Max. Continuous Current (mA) | Max. Pulse Current (mA) | Data Sheet |
|---|---|---|---|---|---|---|---|---|
| EF651615 | LTC-3PN | 400 | 3.6 | 16.8 X 15.8 X 6.8 | 5 | 5 | 20 | |
| EF651620 | LTC-5PN | 550 | 3.6 | 16.8 X 20.1 X 6.8 | 6 | 10 | 20 | |
| EF651625 | LTC-7PN | 800 | 3.6 | 16.8 X 25.8 X 6.8 | 8 | 10 | 30 | |
Wafer Cells
| Model | Size | Nominal Capacity (mAh) | Nominal Voltage (V) | Diameter (mm) | Height (mm) | Weight (g) | Max. Continuous Current (mA) | Max. Pulse Current (mA) | Data Sheet |
|---|---|---|---|---|---|---|---|---|---|
| ER35L65 | 1/10d | 1000 | 3.6 | 32.9 | 7.1 | 19 | 10 | 50 | |
| ER32L100 | 1/6D | 1700 | 3.6 | 32.9 | 10.5 | 24 | 10 | 50 | |
High Temperature Cells
High Temperature Li/SOCl2 Battery has the features of high specific energy and low self-discharge rate, can work in a wide operating temperature range of -40 ℃ ~ +145 ℃ and anti-vibration, anti-shock, and heat dissipation with the special structure and formula design; It is mainly used in the field of oil & gas drilling, exploration, pipeline inspection.
High Temperature Cells
| Model | Size | Nominal Capacity (mAh) | Nominal Voltage (V) | Diameter (mm) | Height (mm) | Weight (g) | Max. Continuous Current (mA) | Max. Pulse Current (mA) | Data Sheet |
|---|---|---|---|---|---|---|---|---|---|
| ER14250MR | 1/2AA | 800 | 3.6 | 14.5 | 25.2 | 10 | 40 | 100 | |
| ER14505MR | AA | 1800 | 3.6 | 14.5 | 50.5 | 18.5 | 80 | 200 | |
| ER211020MR | CC | 10000 | 3.6 | 25.2 | 102 | 100 | 400 | 400 | |
| ER26500MR | C | 6500 | 3.6 | 25.2 | 50 | 55 | 230 | 300 | |
| ER26760MR | 3/2C | 11000 | 3.6 | 25.4 | 76 | 85 | 800 | - | |
| ER32615MR | D | 13000 | 3.6 | 33.2 | 61.5 | 108 | 700 | 350 | |
LiMN02
Lithium manganese dioxide cells have a metallic lithium cathode (the lightest of all the metals) and a solid manganese dioxide anode, immersed in a non-corrosive, non-toxic organic electrolyte. They deliver a nominal voltage of 3V and are cylindrical in shape, with spiral electrodes.
Key Features
- High and Stable operating voltage
- Wide Operating Temperature Range: cylindrical battery: -40℃~85℃; Coin Battery: -20℃~70℃，TPMS: -40℃~125℃.
- High Energy Density
- Low self-discharge rate: (less than≤2% per year at 20℃),
- UL recognized (file number MH28717)
- UN recognized
- RoHS compliance
Standard Type
| Model | Nominal Capacity (mAh) | Nominal Voltage (V) | Diameter (mm) | Height (mm) | Weight (g) | Max. Continuous Current (mA) | Max. Pulse Current (mA) | Data Sheet |
|---|---|---|---|---|---|---|---|---|
| CR2 | 850 | 3 | 15.6 | 27 | 13 | 1000 | 2000 | |
| CR17335 | 1500 | 3 | 17 | 33.5 | 17 | 700 | 2000 | |
| CR123A | 1500 | 3 | 17 | 34.5 | 17 | 1500 | 3000 | |
| CR17450 | 2400 | 3 | 17 | 45 | 42 | 1500 | 3000 | |
| Model | Nominal Capacity (mAh) | Nominal Voltage (V) | Size (mm) | Weight (g) | Max. Continuous Current (mA) | Max. Pulse Current (mA) | Data Sheet |
|---|---|---|---|---|---|---|---|
| CR-P2 | 1500 | 10.8 | 35 X 19.5 X 36 | 42 | 1500 | 3000 | |
| CR9V/P | 1200 | 9 | 26.2 X 17.2 X 48.8 | 43 | 120 | 400 | |
Available in South Africa
For further queries, email us at info@evebattery.co.za.
